• Nest, a Node.js framework, simplifies API development by providing a module that integrates with the OpenAPI specification.

• By leveraging decorators, Nest allows developers to generate comprehensive API documentation without the need for separate tools or manual intervention.

• This intuitive and automated process saves time, reduces human error, and enhances collaboration between development teams and API consumers.

• Nest's integration with the OpenAPI specification redefines how API documentation is built, ensuring robust, performant, and impeccably documented APIs within a single workflow.

Step-by-step instructions with thorough explanations for adding the required files and configurations to produce and set up Swagger documentation for your NestJS API:

Step 1: Create a new NestJS project using the CLI:

nest new demo-api
cd demo-api

Generate a REST API with CRUD endpoints

nest generate resource demo --no-spec

Choose REST API as the transport layer and confirm producing CRUD entry points throughout the creation process.

Step 2: Install Swagger and its Express UI library

npm install --save @nestjs/swagger swagger-ui-express

Step 3: Swagger configuration

• Open the main.ts file in the NestJS project's root directory.

• Import the following modules at the start of the file:

import { NestFactory } from '@nestjs/core';
import { SwaggerModule, DocumentBuilder } from '@nestjs/swagger';
import { AppModule } from './app.module';

Create a DocumentBuilder setting for your API documentation within the bootstrap function

async function bootstrap() {
  const app = await NestFactory.create(AppModule);

  const config = new DocumentBuilder()
    .setTitle('Demo API')
    .setDescription('A Demo API with CRUD functionality')
    .setVersion('1.0')
    .build();

Generate the Swagger document with the following configuration

  const document = SwaggerModule.createDocument(app, config);

Set up the Swagger UI interface using the generated document:

  SwaggerModule.setup('api', app, document);

Start your Nest application:

  await app.listen(3000);
}
bootstrap();

Step 4: Examine the Swagger UI

npm run start

Navigate to http://localhost:3000/api in your web browser. The Swagger UI interface should display your API documentation. It displays a list of all the endpoints you created in Step 1.

Step 5: Customize API Properties

• Open the create-demo.dto.ts file, which should be in the same directory as your controller (most likely the src/demo folder).

• At the start of the file, add the following imports:

import { ApiProperty, ApiPropertyOptional } from '@nestjs/swagger';

• Add the @ApiProperty and @ApiPropertyOptional decorators to the CreateDemoDto class to alter the properties in the Swagger documentation:

export class CreateDemoDto {
  @ApiProperty({
    type: String,
    description: 'This is a required property',
  })
  property: string;

  @ApiPropertyOptional({
    type: String,
    description: 'This is an optional property',
  })
  optionalProperty?: string;
}

Step 6: Set API Responses

• Open the demo.controller.ts file from the src/demo folder.

• At the start of the file, add the following imports:

import { ApiTags, ApiCreatedResponse, ApiUnprocessableEntityResponse, ApiForbiddenResponse, ApiOkResponse, ApiNotFoundResponse, ApiUnprocessableEntityResponse } from '@nestjs/swagger';

• To set API replies for your controller methods, use the necessary decorators. Here are some examples of several methods:

POST Method:

@Post()
@ApiCreatedResponse({ description: 'Created Successfully' })
@ApiUnprocessableEntityResponse({ description: 'Bad Request' })
@ApiForbiddenResponse({ description: 'Unauthorized Request' })
create(@Body() createDemoDto: CreateDemoDto) {
  return this.demoService.create(createDemoDto);
}

GET Methods:

@Get()
@ApiOkResponse({ description: 'The resources were returned successfully' })
@ApiForbiddenResponse({ description: 'Unauthorized Request' })
findAll() {
  return this.demoService.findAll();
}

@Get(':id')
@ApiOkResponse({ description: 'The resource was returned successfully' })
@ApiForbiddenResponse({ description: 'Unauthorized Request' })
@ApiNotFoundResponse({ description: 'Resource not found' })
findOne(@Param('id') id: string) {
  return this.demoService.findOne(+id);
}

PATCH/UPDATE Method:

@Patch(':id')
@ApiOkResponse({ description: 'The resource was updated successfully' })
@ApiNotFoundResponse({ description: 'Resource not found' })
@ApiForbiddenResponse({ description: 'Unauthorized Request' })
@ApiUnprocessableEntityResponse({ description: 'Bad Request' })
update(@Param('id') id: string, @Body() updateDemoDto: UpdateDemoDto) {
  return this.demoService.update(+id, updateDemoDto);
}

DELETE Method:

@Delete(':id')
@ApiOkResponse({ description: 'The resource was returned successfully' })
@ApiForbiddenResponse({ description: 'Unauthorized Request' })
@ApiNotFoundResponse({ description: 'Resource not found' })
remove(@Param('id') id: string) {
  return this.demoService.remove(+id);
}

Step 7: Examine the Swagger UI

Start your Nest application

npm run start

• Navigate to localhost:PORT>/api in your web browser. Replace PORT> with the port number of your application (often 3000).

• You may now add tags, descriptions, and examples to your controller methods and DTOs to personalize your Swagger documentation.
